LiFePO4 Battery 300Ah
The LiTime 12V 300Ah is a LiFePO4 battery with 3840Wh of energy and a 200A BMS for continuous charge and discharge current. It is rated for 4,000 cycles at 100% depth of discharge (15,000 at 60%), IP65, and up to four units in series and four in parallel (4S4P).
Buy — affiliate linkAdd to my wiring diagram
We earn a small commission on purchases through this link. It does not change what you pay and never affects ratings.
Power
3840 W
Input
12.8 V
Output
12.8 V DC
!
Safety notes for this component
- Size cables and the main fuse for the 200A continuous BMS current.
- Do not charge below 0°C: the base model has no low-temperature charge cut-off, so keep it in a heated space or use a charger with a temperature sensor.
- Do not connect batteries of different chemistries, brands, models or capacities in series or parallel.
- Not for use as a car starter battery.
Technical data
Battery Capacity300Ah
Battery Energy3840Wh
Nominal Voltage12.8V
BMS Continuous Charge/Discharge Current200A
Recommended Charge (CC/CV)14.4V ± 0.2V, 60A
Charge Temperature Range0°C ~ 50°C
Discharge Temperature Range-20°C ~ 60°C
Cycle Life4,000 at 100% DoD, 6,000 at 80% DoD, 15,000 at 60% DoD
Ingress ProtectionIP65
Max Series/Parallel4S4P
TerminalsM8
Dimensions52.2 × 23.7 × 21.8 cm
Weightapprox. 28.5 kg
