EPEVER Tracer 4210AN G3 40A MPPT Controller
The EPEVER Tracer 4210AN G3 is a 40A MPPT charge controller for 12V/24V systems, featuring a maximum PV input voltage of 100V and a rated charging power of 520W at 12V or 1040W at 24V. It offers up to 99.5% tracking efficiency and 98% conversion efficiency.
Buy — affiliate linkAdd to my wiring diagram
We earn a small commission on purchases through this link. It does not change what you pay and never affects ratings.
Power
960 W
Input
100 V DC
Output
24 V DC
!
Safety notes for this component
- Install the controller in a well-ventilated place, as its heat sink may become hot during operation.
- Disconnect PV array connections and the battery's fuse/breaker before controller installation.
- A fast-acting fuse, 1.25 to 2 times the controller's rated current, must be installed on the battery side within 150mm of the battery.
- The negative terminals of the PV array, battery, and load can be grounded simultaneously, or any single negative terminal can be grounded; the shell's grounding terminal must be grounded.
- When the controller's internal temperature reaches 81℃, charging power is automatically reduced; if it exceeds 85℃, charging stops.
Technical data
Rated Charge Current40A
Rated Discharge Current40A
Battery Rated Voltage12/24VDC Auto-recognition
PV Maximum Open-circuit Voltage100V (At minimum operating environment temperature); 92V (At 25℃)
MPPT Voltage Range(Battery voltage +2V) to 72V
Rated Charging Power520W/12V, 1040W/24V
Work Temperature Range-25℃ to +45℃ (100% loads working)
Grounding TypeCommon negative
RS485 Port5VDC/200mA (RJ45)
EnclosureIP30
