Pure Sine Wave Inverter 1000WIn library
Renogy

Pure Sine Wave Inverter 1000W

The Renogy 1000W Pure Sine Wave Inverter converts 12V DC power to 120V AC power. It offers a continuous output of 1000W with a surge capacity of 2000W, suitable for various off-grid applications.

Buy — affiliate linkAdd to my wiring diagram

We earn a small commission on purchases through this link. It does not change what you pay and never affects ratings.

Power
1000 W
Surge
2000 W
Input
12 V DC
Output
230 V AC
Price check
≈ €160€16 per 100 W

among the cheapest of 4 inverters in the catalogue (€12–€24 per 100 W).

Estimated street price; the shop shows today's price.

!

Safety notes for this component

  • Ensure all connections going into and from the inverter are tight; sparks may occur, so keep flammable materials away.
  • The inverter is suitable for 12V battery banks ONLY.
  • Confirm the polarity of the devices before connection to prevent injury and damage.
  • To minimize sparking during connection, use appropriately sized wires and consider an external fuse.
  • An external fuse of 150A is recommended for the 1000W model.

Try it with your setup

What it runs

Against 1000 W continuous and 2000 W surge, one appliance at a time.

Laptop charger65 WRuns
Starlink dish75 WRuns
230 V compressor fridge100 WRuns
Corded power drill600 WRuns
Hair dryer1200 WToo big
Microwave (input power)1200 WToo big
Pod coffee machine1400 WToo big
Induction hob, one zone2000 WToo big
Kettle2000 WToo big

Start-up draw from the appliance type: compressor fridges pull about 5× their running power, motors 3×, pumps 4×.

Size an inverter for several appliances at once →

Wiring it in

Current, fuse and cable size for the Pure Sine Wave Inverter 1000W at full rated power.

Battery → inverter

DC input · 12 V
Current at rated power
92.6 A
Start-up surge
185.2 A
Fuse
125 A ANL
Cable run (one way)CableVoltage drop
1 m50 mm² · 1/0 AWG0.6 %
2 m50 mm² · 1/0 AWG1.1 %
3 m50 mm² · 1/0 AWG1.7 %
5 m50 mm² · 1/0 AWG2.8 %
Other length or voltage? Open the wire gauge calculator →

Copper cable at 20 °C, positive and negative conductor, at most 3 % voltage drop. The cable is always rated for the fuse that protects it, and the fuse is sized at 125 % of the current. Input current assumes 90 % conversion efficiency. If the manufacturer manual specifies a fuse or cable, follow the manual.

Technical data

Continuous Output Power1000W
Peak Power Rating2000W
Output Voltage120V
Output Frequency60 Hz ± 0.1%
AC Output Sockets2
AC Terminal Block1
USB Power Port5V/2.1A
Output WaveformPure Sine Wave
Nominal Efficiency> 90%
Total Harmonic Distortion< 3% Linear Load < 5% Non-linear Load
Nominal Input Battery Voltage12V
Low Battery Alarm10.5V ± 0.5V DC
Battery Low Shutdown10.0V ± 0.5V DC
High Voltage Alarm16V
Over Voltage Shutdown16.5V ± 0.5V DC
No Load Current Draw< 1A
Dimensions12.9 x 6.8 x 3.3 in
Weight6.0 lb
Operating Temperature Range-4°F - 104°F
